(Freight Inlcuded)E Ink 11.6 inch tri-color E-paper digitalsignage

by GoodisplayEpaper 0 orders


$157.00

Model Name:GDEH116Z91
SIZE:11.6 inch
IC:SSD1677
RESOLUTION:960×640
OUTLINE SIZE(mm):254.31×176.35×0.85
ACTIVE SIZE(mm):244.512×163.008
PIXEL PITCH(mm):0.2547×0.2547
OPERATING TEMP.:0℃~35℃
STORAGE TEMP.:0℃~35℃
CONNECTOR:24 Pin FPC
FULL REFRESH(s):30
POWER CONSUMPTION OF THE REFRESH(mW):33
STANDBY POWER CONSUMPTION (mW):0.0115

Share
Tweet
Share
Reddit
Vote
0 Shares

Good e-Reader Protection Plan

Extend your e-reader warranty for two years. Good e-Reader will coordinate the repairs with the manufacturers if your device is damaged during this time.

SKU: GDEH116Z91 Categories: , Tags: , , , , , , , , , , , , ,

Description

EPD (Electronic Paper Display, e-paper) is a special type of display that does not need electricity to sustain the projected image. Just like real paper, e-paper also does not require backlight and the displayed image resembles ink on paper (hence the name). Thanks to minimal energy requirements, perfect readability in the sunlight and unlimited viewing angles, EPD displays are the best choice for many industrial and consumer applications such as: e- prices, weather stations, smart homes, modern timetables, interactive signs, badges, smart watches. This is a 11.6 inch eink ePaper display with 960×640 resolution, SPI interface, capable of displaying images in black, white and red. Due to the bi-stable, the image once updated can stay on the display even when power is completely disconnected. The image is also high contrast and readable under sun just like printed paper. It is a perfect match for appliances like e-shelf label, smart tag, smart home application, industrial instrument and other related products.

NOTE: Once you purchased this 11.6 inch E Ink panel, we will arrange the shipment via FedEx/DHL to insure you get the package soon and safe. The PRICE (for this item + default shipping cost together )and we won’t charge you more shipping cost. We shall process your order promptly once payment is done.

Since E-paper display is a new thing to many people they may ask what exactly it can be used for.
Here are just some cases but we super-look forward to seeing YOU to excel and develop this tiny gadet beyond our imagination.

◇ Logistics
◇ Reusable Transit Item
◇ Station Terminal
◇ Smart Card
◇ Smart Identity Tag
◇ Seat Number Tab
◇ Smart Luggage Tag
◇ Smart Coffee Cup
◇ Smart Home Application
◇ Identification & Access
◇ Display the Latest Weather Forecast
◇ Display Your Own Twitter Feed
◇ E-paper room booking system
◇ Bitcoin price ticker
◇ Other IoT (Internet of Things) Devices
◇ 1D/2D Barcode Electronic Shelf Label
******A long list still waiting for your extraordinary creation******

FLEXIBLE PURCHASE OPTION

*If you want to add DESPI-C02 individually into your CART, PLEASE CLICK THE PICTURE BELOW:



WATCH THE VIDEO

RELATED INFORMATION FOR DOWNLOADING

GDEH116Z91 Specification

IC Driver SSD1677

GDEH116Z91 STM32 Sample Code

GDEH116Z91 ESP32 Sample Code



SELECTION GUIDE

PART NUMBER SIZE IC COLOR GREYSCALE RESOLUTION ACTIVE SIZE(mm) FULL REFRESH TIME (S) OPERATING TEMP. PARTIAL REFRESH INTERFACE
GDEW0102T4 1.02” UC8175 BW 2 128×80 21.76×14.00 3 0℃~50℃ √ SPI
GDEW0102I3F（FLEXIBLE） 1.02” UC8175 BW 2 128×80 21.76×14.00 3 0℃~50℃ √ SPI
GDEW0154M09 1.54” JD79653 BW 2 200×200 27.60×27.60 0.82 0℃~50℃ √ SPI
GDEW0154T8D 1.54” UC8151D BW 4 152×152 27.51×27.51 3 0℃~50℃ √ SPI
GDEH0154Z90 1.54” SSD1681 BWR 2 200×200 27.00×27.00 15 0℃~40℃ SPI
GDEW0213I5FD（FLEXIBLE） 2.13” UC8151D BW 4 212×104 48.55×23.71 3 0℃~50℃ √ SPI
GDEM0213B74 2.13” SSD1680 BW 4 250×122 48.55×23.70 3 0℃~50℃ SPI
GDEY0213Z98 2.13” SSD1680 BWR 2 250×122 48.55×23.70 14 0℃~40℃ SPI
GDEW0213T5D 2.13” UC8151D BW 4 212×104 48.55×23.71 3 0℃~50℃ √ SPI
GDEW0213T5D-FL01(With Frontlight) 2.13” UC8151D BW 4 212×104 48.55×23.71 3 0℃~50℃ √ SPI
GDEW026T0D 2.6” UC8151D BW 4 296×152 60.09×30.70 3 0℃~50℃ √ SPI
GDEW027W3 2.7” EK79652 BW 4 264×176 57.29×38.19 3 0℃~50℃ √ SPI
GDEW027W3-T(With Touch Panel) 2.7” EK79652 BW 4 264×176 57.29×38.19 3 0℃~50℃ √ SPI
GDEH029Z13 2.9” UC8151D BWR 2 296×128 66.90×29.06 15 0℃~40℃ SPI
GDEW029I6FD（FLEXIBLE） 2.9” UC8151D BW 4 296×128 66.90×29.06 3 0℃~50℃ √ SPI
GDEW029T5D 2.9” UC8151D BW 4 296×128 66.90×29.06 3 0℃~50℃ √ SPI
GDEW029T5D-FL02(With Frontlight) 2.9” UC8151D BW 4 296×128 66.90×29.06 3 0℃~50℃ √ SPI
GDEW0371W7 3.71” UC8171 BW 4 416×240 81.54×47.04 4 0℃~50℃ SPI

SIZE ABOVE 4.2”

PART NUMBER SIZE IC GREYSCALE RESOLUTION ACTIVE SIZE(mm) FULL REFRESH TIME (S) OPERATING TEMP. INTERFACE
GDEW042C37 4.2” UC8176 2 400×300 84.80×63.60 28 0℃~40℃ SPI
GDEW042T2 4.2” UC8176 4 400×300 84.80×63.60 3 0℃~50℃ SPI
GDEH042Z21  4.2” UC8276 2 400×300 84.80×63.60 15 0℃~40℃ SPI
GDEW0583C64 5.83” UC8159 2 600×448 118.80×88.26 25 0℃~40℃ SPI
GDEW0583T8 5.83” UC8179 2 648×480 119.23×88.32 4 0℃~50℃ SPI
GDEW0583Z83 5.83” UC8179 2 648×480 119.23×88.32 12 0℃~40℃ SPI
GDEY075Z08 7.5” UC8179 2 800×480 163.20×97.92 12 0℃~40℃ SPI
GDEY075T7 7.5” UC8179 4 800×480 163.20×97.72 3 0℃~50℃ SPI
